49107-10
STEEL BOX2 SPRING BUFFER STOP
Metal shock absorber to protect the loading and unloading dock from impacts received by trucks entering the dock to load.
Description:
SteelBox2 spring buffers are oversized for increased shock absorption. They prevent wear and tear of the buffers from vibrations during the loading and unloading process. The inner shock absorbers are completely protected from external elements as they are not exposed, thus extending their service life. Galvanized steel finish with no welds or weak points. Rubber buffers integrated in the interior. Steel structure with 1 cm thick front shock plate.Long
250 mm
Material
Galvanized Steel
High
540 mm
Dimensions
Thickness 110 mm
Weight
28,55Kg
Features
High quality, maximum resistance and durability of the product. The bumpers are designed to effectively absorb impacts, thanks to the rubber bumpers that are protected by the high-strength steel structure from deformation. The high-performance design ensures long service life of the bumper system and effective protection of the loading dock structure. The SteelBox2 is ideal for installation on original or retrofit equipment. Structure made of bent steel with no welds or weak points. Quick and easy to install, with dowels or direct welding to the dock. Ideal as a replacement for existing rubber buffers. A complete spare parts kit is available upon request. The system consists of: 1 forntal plate with integrated bumpers 1 back plate for installation to the dock 2 through tubes, 4 washers and 4 pins.
Usage
Safeguard loading and unloading docks. Protects the dock from impacts received by trucks entering the dock to load.
