Vehicle Restraint Belts and Restraint Carriers

The equipment for fastening and stowage in vehicle platforms necessary for the logistics of utility vehicles, light and heavy vehicles.

Vehicle-carrying trucks must be equipped with 4 wedges or chocks per vehicle transported. They must also have 2 lashing belts per vehicle transported.
transported.

The belts must be at least 2.2 m long and have a maximum belt elongation of 4%. They must comply with EN 12195-2.

Features

The vehicle restraint belts are manufactured in standard and customized sizes, always in accordance with the current EN12195-2 standard.

There are different types of configuration depending on the need of each transport, amares with swivel hooks, with protections, with cleats, different types of ratchet tensioners and lengths and colors for the belt.

Advantages

  • Standard and custom manufacturing.
  • Product customization.
  • Standard EN 12195-2.
  • High quality components.
  • Technical advice.

Regulations

The European Standard that applies to lashings is EN-12195-2. Devices for lashing loads on road vehicles, made of synthetic fibers. The standard applies to all European Union countries, many of which are already carrying out control and sanction measures.

This standard specifies the safety requirements relating to the manufacture and use of lashing devices made from technical textiles for multiple uses. As well as test methods for load lashing straps, hazards and composite load lashing devices.

LABEL IN ACCORDANCE WITH STANDARD EN 12195-2

Cargo lashing belts manufactured in accordance with EN12195-2 must have a blue label indicating that they are manufactured in polyester.
Each part of a lashing assembly shall have the blue identification label, which shall contain data that enables its identification, determination of specifications and traceability of its manufacture and distribution.

Before each use, the belt should be inspected to ensure that it is free of defects and that the identification and specification are correct.

A belt without identification (valid blue tag) should never be used.

During the period of use, regular checks should be made for defects or damage. These checks should extend to any fittings or accessories used in conjunction with the belt.

If there is any doubt as to the belt's suitability for use, the belt should be removed from service until it is examined by a competent person.

Instructions

THE FASTENING OF VEHICLES

  1. Attach the first hook to the floor element, so that the strap slides as vertically as possible.
  2. Then tie the belt radially above the wheel, making sure that the control belt is positioned correctly.
  3. Attach the second hook to the floor element in the same manner as the first.
  4. Attach the third hook to the anchor point lying laterally outside the wheel and tighten the strap using the ratchet.

SECURING OF LOADED VEHICLES IN THE DIRECTION OF TRAFFIC

  1. One chock in front and one behind on the rear wheel.
  2. Additionally tie this rear wheel by means of a third anchor point.
  3. Diagonally to this wheel place another wedge in front of the respective front wheel.
  4. If a chock cannot be used for technical reasons, a new wheel must be secured with an anchor strap.

SECURING OF LOADED VEHICLES IN THE OPPOSITE DIRECTION OF TRAFFIC

  1. One chock in front and one behind on the rear wheel.
  2. Diagonally to this wheel place another wedge in front of and behind the respective front wheel.
  3. Additionally, tie both wheels by means of a third anchor point on each wheel.
  4. If the chock cannot be used for technical reasons, a new wheel must be secured with a tie-down strap.

Three-point belts with a grip sleeve and in combination with chocks must be used to properly secure vehicles in a vehicle carrier.

  • Before loading/unloading, the vehicle carrier must be parked on solid ground.
  • The loading platform must be clear of tie-down belts, chocks, tools, etc.
  • Vehicle carrier covers must be positioned and secured in the proper position to load vehicles without damaging their undersides.
  • The different decks of the truck and trailer must be connected with connecting ramps/bridges.

Products

Swivel hook 50mm

Part number: 1ZEB

Tensioner with swivel hook 50mm short and narrow shank

Part number: 5N2ZE

50mm Vehicle Carrier Belt with grip cleats. Tensioner with short and wide handle

Part number: 9Q2GG25AZ60T

Carrier belt 50mm with Mercedes protection. Tensioner with short and wide handle

Part number: 9Q2GG25AZ60M

Vehicle Belt Carrier 50mm with third fixed hook and tensioner with short and wide handle

Part number: 9Q2GG25AZ60

Plate with 3mm steel trepanning hole

Part number: 70873-300/75

Plate with 3mm steel trepanning hole

Part number: 70873-300/65

Plate with 3mm steel trepanning hole

Part number: 70873-200/75

Plate with 3mm steel trepanning hole

Part number: 70873-200/65

Plate with 3mm steel trepanning hole

Part number: 70873-200/50

50mm Vehicle Carrier Belt with gripping cleats. Tensioner with short and narrow handle

Product reference: 5N2GG25AZ60T

Carrier belt 50mm with Mercedes protection. Tensioner with short and narrow handle

Product reference: 5N2GG25AZ60M

Vehicle Belt 50mm

Product reference: 5N2GG20AZ60

Tensioning swivel hook 35mm

Part number: 2ZEB

Ratchet tensioner with swivel hook 50mm

Part number: 9Q2ZE
